What is PV Combiner Box?

People are increasingly concerned about their energy bills and the rising nature of cheap solar power. But the solar panels often share systems such as wiring and connectors. Creating multiple solar panel connections in one pack is a challenge that is a complicated problem.

It can cause severe injuries without knowing anything about connections. It would help ensure that the cables are correctly connected and well. Many people can’t figure out how to combine many panels in one pack. It’s frustrating and time-consuming.

The photovoltaic combiner box is an innovative technology. You can connect wires with standard connectors and use the combiner box like a regular shelf. No longer will you need to buy multiple units and install them in different spots.

The combiner box PV system is a unique mount box that combines multiple panels into a single box. It makes retrofitting your storage room more straightforward than ever before.

The iron body PV combiner box function has a high voltage-resistant structure, high strength, and low weight. It protects the circuit from voltage fluctuations and lightning damage.

It is made with a spray-coated iron sheet that has maximum reliability. In addition, its compact size enables a cost-effective and straightforward assembly. It reduces the fabrication costs and simplifies the installation processes at all levels.

The plastic body combiner box has high insulation, low thermal expansion, and excellent mechanical properties. It is easy to install and convenient to maintain and repair. This type of body has strong corrosion resistance.

The conductive layer will not corrode, and you can clean it easily. You can use it in severe conditions such as high and low temperatures. PV combiner box function protects electrical components from bad weather, dust, and foreign matter interference.

We have been manufacturing and supplying equipment in an emerging market for renewable energy sources (RES). You can implement them in residential, commercial, industrial, and utility-scale PV systems.

GREEN LIFE FROM PHOTOVOLTAIC ASSESSORIES

Many people don’t understand what Photovoltaic Accessories are. Why do we use them on our solar panel systems? How do they help harness more power from the sunlight for our homes and businesses?

This article will help you know about important points about Photovoltaic Accessories which will help you understand their importance in the photovoltaic system.

A photovoltaic system is a technology for converting light into electricity using solar panels. Solar panels are usually used with other components like; batteries, inverters, mounts, and other parts called photovoltaic accessories.

Photovoltaic Accessories are the tools necessary for the various functions of the solar panel system as one part of this system. HANMO’s PV accessories improve the performance and efficiency of your solar panel system. These accessories enable fights against environments like rain, snow, and sunlight.

FPRV-30 DC Fuse is an electrical safety device that operates to provide overcurrent protection of an electrical circuit. In a dangerous condition, the fuse will trip, stopping the flow of electricity.
The PV-32X, the new fuse from DC, is suitable for all 32A DC applications. It is defined as a fuse that helps avoid current damage or destroy expensive equipment or burn wires and components.
It uses UL94V-0 thermal plastic case, overcurrent protection, anti-arc, and anti-thermal contact.
Features
●Fuses can be used in a variety of applications.
●It is convenient and easy to replace without being overcharged for the “service call.”
●FPRV-30 DC fuse repairs your thermal fuse faster than a standard fuse.
●It is the only easy, affordable plug-and-play device for home and commercial.
●If there is an overload or short circuit, the dc fuse will trip off immediately to protect PV panels.
Benefits
●DC fuse provides overcurrent protection of an electrical circuit and will trip open a circuit to prevent an electrical fire.
●It protects your home electronics, as well as your safety.
●DC fuse allows your electrical system to function as its designers intended; there’s no need to worry about fuses blowing when the lights are left on.
●DC fuse protects you by making sure the power is switched off before working on your electrical system.
●It is the best choice for dc circuit protection, suitable for solar panels, inverters-u pipe, and other electrical parts.
The MC4 Connector is the most commonly used Connector for the PV system. MC4 Connector is defined as the Connector that allows users to directly connect the solar panel to an inverter without considering an anti-reverse device.
The MC in MC4 stands for multi-Contact, while the 4 refers to the contact pin’s 4 mm diameter.
Features
●MC4 Connector provides a more stable and smooth way to connect solar panels, especially in an open-roof system.
●The stronger self-locking pins of connectors provide a more stable and secure connection.
●It uses waterproof, high-strength, and pollution-free PPO material.
●Copper is the best conductor of electricity, and it’s an important element in the MC4 solar panel cable connector.
Benefits
●MC4 Connector is environmentally friendly and recyclable.
●It can save 70% losses reduced by DC-AC conversion.
●A thick copper core ensures years of use with no temperature or UV light exposure effects.
●Stable self-locking makes it easier to use MC4 Connectors with thicker cables in the case of photovoltaic applications.
Using good products will increase the life span of your PV system. HANMO’s Photovoltaic Accessories enhance the efficiency of a solar panel due to their compact size, budget-friendly, limited space, and easy installation. These products make everything perfect in your PV system.

WHAT IS CHANGEOVER SWITCH ?
The main function of the cam universal conversion switch is to convert the current, and this kind of switch use is quite common. The universal transfer switch needs to be operated properly, otherwise it is prone to circuit failure. The use of this switch has conditional restrictions, to the surrounding environment requirements are more strict, can not be used in the ultra-high temperature or ultra-low temperature environment, otherwise it will damage the switch. Next, xiaobian to take you to understand how to operate the universal conversion switch.

1. How does the cam universal converter switch operate

1. Use the handle to drive the rotating shaft and cam push contacts to be on or off. Due to the different shape of the cam, the coincidence situation of the contact is different when the handle is in different positions, thus achieving the purpose of the conversion circuit.

2. Common products include LW5 and LW6 series. The LW5 series can control small capacity motors of 5.5kW and below; the LW6 series can only control small capacity motors of 2.2kW and below. When used for reversible operation control, a reverse start is allowed only after the motor has stopped. LW5 series universal converter switch can be divided into self-duplex and self-positioning mode according to the handle. The so-called self-duplex is to use the handle in a certain position, the hand release, the handle automatically return to the original position; positioning refers to the handle is placed in a position, can not automatically return to the original position and stop in the position.

3. The handle operation position of the universal transfer switch is indicated by an Angle. The handles of different models of the universal converter switch have different contacts of the universal converter switch. The graphic symbols in the circuit diagram are shown in the figure below. However, since the engagement state of the contact point is related to the position of the operating handle, the relationship between the operating controller and the engagement state of the contact point should also be drawn in the circuit diagram. In the figure, when the universal converter switch hits left 45°, contacts 1-2,3-4,5-6 close and contacts 7-8 open; at 0°, only contacts 5-6 are closed, and at right 45°, contacts 7-8 are closed and the rest open.

2. How to connect the universal converter switch

1. The LW5D-16 voltage conversion switch has a total of 12 contacts. Facing the front side of the switch, the switch is divided into the left and right four w positions. Panel indicates 0 top, neutral, AC left, AB right and BC bottom. Behind the panel is the terminals. Also divided into up and down around. Let’s talk about it first.

2. The left 6 terminals have been connected to the factory, from the front to the back, respectively, top 1, bottom 3 is the first group, phase A, top 5, bottom 7, group 2, phase B, top 9, bottom 11, group 3. The first contacts contact A, the second contacts connect B and the third contacts C.approach.1.3,5.7,9.11 to ABC three-phase.

3. The six terminals on the right are separated up and down, but the top and bottom of the front and rear terminals have been connected respectively. That is, 2,6,10 are the first set of contacts 4,8,12 are the second set of contacts below. That is, 2.6.10 and 4.8.12 connect to the voltmeter. These two sets of contacts are the two lines of voltage connection voltage voltmeter over the two can be arbitrarily connected to these two points, these two points are no sequential points.

4. When the switch handle turns to indicator 0, all terminals are in an open state and no contact is on. When the switch handle to the indicator AB phase, the left front top 1 terminal A terminal and right front first terminal and above 2 points, namely 1,3 end and 2,6,10 end interlinked, at the same time, the left second row, the lower point 7 of B terminal and the right same bottom point 8 connectivity, namely, 5,7 and 4,8,12, from 2,6,10 and 4,8,12 terminals, forming a line voltage loop. This one can be seen clearly when you get the switch. The same reason explains the circuits of AC and BC, respectively.

We have been manufacturing and supplying equipment in an emerging market for CAM switch.
